Avery Dennison® 800 Premium Cast
Avery Dennison® 800 Premium Cast is a unique long-life film range that offers excellent dimensional stability. The face film allows for easy and accurate application of finished lettering and graphics to curved and corrugated surfaces.
Avery Dennison® 800 Premium Cast White and 830 Premium Cast White Matte are manufactured on a blue contrast backing paper for ease of conversion.
Description
Physical Characteristics
| Product | Test Method¹ | Results |
|---|---|---|
| Caliper, facefilm (micron) | ISO 534 | 50 |
| Caliper, facefilm + adhesive (micron) | ISO 534 | 75 |
| Gloss (GU) | ISO 2813 | Gloss 20° 50% / Matt 85° 20% |
| Dimensional stability (mm max.) | FINAT FTM 14 | 0.20 |
| Shelf life (years) | Stored at 22°C / 50% RH | 2 |
| Durability² (Vertical exposure, zone 1) | ||
| – Black & White | 10 years | |
| – All Colours & Transparent | 8 years | |
| – Metallics | 5 years |
Adhesive
| Property | Test Method | Result |
|---|---|---|
| Elongation (%) | DIN 53455 | 130 |
| Adhesion, initial (N/m) | FINAT FTM-1, stainless steel | 500 |
| Adhesion, after 24 hours (N/m) | FINAT FTM-1, stainless steel | 600 |
| Flammability | Self-extinguishing | |
| Accelerated ageing | SAE J 1960, 2000h exposure | No negative impact on film performance |
Temperature Range
| Condition | Value |
|---|---|
| Application temperature (min. °C) | +10 |
| Service temperature (°C to °C) | -40 to +110 |
Chemical Properties
| Test | Exposure | Result |
|---|---|---|
| Humidity resistance | 200 hours exposure | No effect |
| Salt spray resistance | 120 hours exposure | No effect |
| Water resistance | 48 hours immersion | No effect |
About Avery Dennison
Avery Dennison offers premium self-adhesive vinyl films and application tools designed for automotive wraps, architectural surfaces, and commercial signage. Their Supreme Wrapping Film and MPI ranges are globally trusted for ease of use and superior print quality. Avery Dennison is a go-to brand for professional installers and designers seeking durability and performance.
