Keundo SQ-2224E UV Flatbed Printer
- Industrial dye sublimation printer designed for high-volume textile and fabric production
- Equipped with 24 Epson I3200-A1 printheads for ultra-high productivity
- Supports jumbo media rolls up to 10,000 meters for unattended long-run printing
- Advanced linear motor system with negative pressure ink supply for stable, continuous output
Finance Available
Get the equipment you need now and pay monthly.
Available for qualifying businesses. Speak to our team to arrange a quote.
About Keundo
Keundo Equipment
KEUNDO delivers advanced large format printing solutions built for modern print and signage businesses. From UV flatbed and hybrid printers to high-performance production equipment, the brand combines industrial reliability, precision engineering and outstanding print quality to help businesses scale production and expand their creative capabilities.
Large Format Printing
Industrial Print Solutions
High-Speed Production
Technical Specifications
| Model | SQ-2224E |
|---|---|
| Printer Type | Industrial Rubber Roll Dye Sublimation Printer |
| Print Head | Epson I3200-A1 |
| Head Number | 24 |
| Ink Dot Size | 3.5pl |
| Printing Speed | 300dpi (300×1200) – 590 m²/h |
| 360dpi (720×600) – 560 m²/h | |
| 300dpi (300×2400) – 295 m²/h | |
| 360dpi (720×1200) – 280 m²/h | |
| Ink Type | Ultra-high concentration dye sublimation ink |
| Ink Colors | 4 Colors (C / M / Y / K) |
| Ink Supply | Negative pressure ink supply system |
| Ink Capacity | 12L ink tank |
| Printer Width | 2250mm |
| Printing Width | 2050mm |
| X-Axis Drive | Linear motor |
| Encoder Strip | Metal encoder strip |
| Structure | Heavy-duty industrial structure |
| Loading & Take-up Structure | Rear retraction / 10,000m high-performance servo motor system |
| Maximum Media Load | ≤10,000m |
| Minimum Media Weight | ≥28g |
| Drying Structure | External three-stage automatic air and heat integrated dryer |
| Moisturizing Structure | Fully automatic cleaning and moisturizing integrated components |
| RIP Software | Riprint / NeoStampa / Wasatch / Photoprint |
| Image Format | JPG / TIF / PDF / etc. |
| PC Configuration | Win7 64-bit / Win10 64-bit; CPU: i7 processor; 8GB+ RAM; 500GB HDD (SSD recommended); 4GB graphics card |
| Interface | USB 3.0 |
| Power Supply | AC220V ±5%, 16A, 50Hz |
| Power Consumption | Printing system: 5000W |
| Drying system: Max 18KW | |
| Working Environment | Temperature: 15°C – 32°C |
| Humidity: 30% – 75% (no condensation) | |
| Printer Dimensions | 4350 × 2491 × 1925 mm |
| Weight | 1.75T |
