Avery Dennison® 900 Super Cast™
Avery Dennison® 900 Super Cast and Metallic Series films are your ultimate choice for warranted top-of-the-range applications. Their superior conformability and durability deliver extra-special performance in the most challenging situations.
Description
General
| Property | Test Method / Detail | Result |
|---|---|---|
| Roll width, length | 615mm, 1230mm / 50m | |
| Caliper, face film | ISO 534 | 50 micron |
| Caliper, face film & adhesive | ISO 534 | 80 micron |
| Gloss | ISO 2813 @20° | 50% |
| Elongation | DIN 53455 | 150% |
| Dimensional stability | DIN 30646 | 0.15mm max |
| Adhesion, initial | ASTM 1000, Stainless steel | 540 N/m |
| Adhesion, ultimate | ASTM 1000, Stainless steel | 600 N/m |
| Shelf life | Stored at 22°C / 50% RH | 2 years |
| Flammability | Self extinguishing | |
| Expected Durability (Vertical exposure) | ||
| – Black and white | Up to 12 years | |
| – All colours and transparent | Up to 10 years | |
| – Metallics | Up to 5 years |
Thermal
| Property | Value |
|---|---|
| Application temperature (min.) | +10°C |
| Temperature range | -50°C to +110°C |
Chemical
| Test | Exposure | Result |
|---|---|---|
| Humidity resistance | 120 hours exposure | No effect |
| Corrosion resistance | 120 hours exposure | No contribution to corrosion |
| Water resistance | 48 hour immersion | No effect |
| Chemical resistance | Mild acids, mild alkalis | No effect |
| Solvent resistance | Applied to aluminium | No effect except to: oils, greases, aliphatic solvents, motor oils, heptanes, kerosene, JP-4 fuel |
